Workstation Jib Cranes

Enclosed track workstation jib cranes provide flexible circular area coverage

gorbel_logo2018

Workstation Jib Cranes provide excellent coverage for smaller areas not suited to larger workstation bridge cranes.

They are the ideal substitute for traditional, heavy I-Beam Jib Cranes. These jibs are designed to service circular areas and support tool balancers, air balancers, vacuum lifters, and hoists.

When floor mounted, they can accommodate up to a 360° rotation. When column or wall-mounted, they allow up to a 200° rotation. Capacities are available from 50kg. to 500 kg. with spans up to 4.8m.

Features

  • Lightweight jib crane with capacities from 50kg to 500kg
  • Freestanding Jib Crane column allows 360 degree rotation to maximise lifting area
  • Wall mounted Jib Crane avoids any structure impacting your work area and offer 200° rotation
  • Enclosed track design allows efficient movement and improved performance compared to I-Beam style jibs
  • Most can be bolted directly to existing floor without adding special foundations
  • Utilize enclosed track for the boom assembly, which reduces dead weight for easier rotation than traditional I-Beam Jibs
  • Feature a retaining pin through the pivot pin to help resist accidental upward dislodgment of the boom assembly
  • Include hoist trolley
  • Roller bearings provide for unsurpassed ease of movement
  • Spans up to 4800mm

Applications

  • Food Manufacturers raw material handling
  • Finished Goods Palletising boxes
  • Combined with vacuum lifters
  • Machining shops component loading

Freestanding Jib Cranes
– WSJ 360

The Gorbel workstation free standing jib crane provides a full 360 degree rotation. A freestanding jib requires just the one footing per installation, helping to minimise the space requirements, and making it easier to manoeuvre. The Gorbel workstation free standing jib cranes are easier to move and position than traditional I-beam jibs. The cold – formed, high strength enclosed track design keeps rolling surfaces clean, and the tracks low weight per metre reduces the dead weight of the boom.

wsj_large

Wall Mounted Jib Cranes
– WSJ 200

Gorbel workstation wall mounted jib cranes provide excellent coverage in a circular area, ideal for smaller spaces. Providing 200 degree rotation when wall mounted, this workstation crane configuration minimises any structure requirements at ground level.

wsj200_large
